IBDRW100-EX

Name: IBDRW100-EX
SKU: GW50582095
Availability: InStock

DIN Rail Box Embedded PC with ATEX, Celeron N2930

Pro zobrazení cen se prosím přihlaste.

Porovnat

Číslo zboží: GW50582095 Produktové číslo: IBDRW100-EXKategorie: Na DIN lištu, SpeciálníVýrobce:

Poptat produkt

IBDRW100-EX-Winmate Bay Trail Slim DIN Rail PC Embedded Automation Controller

Features

Ľ Design for Industrial Automation, Din Rail application
Ľ Onboard Intel Celeron Quad-Core N2930 1.83GHz
Ľ 1 x DDR3L SODIMM slot, max. 8GB
Ľ 1 x RS232 / 422 / 485 communication, switch by jump (Default:RS232)
Ľ 4 x Giga LAN, 1 x USB 3.0, 3 x USB 2.0, 1 x VGA,
1 x Line out, 1 x Power Jack
Ľ Fanless ,High effciency thermal design
Ľ ATEX & C1D2 Certification *
Ľ AWS loT Greengrass Certified

System Specification

Processor	Intel® Celeron® Bay Trail-M N2930 1.83GHz
System Chipset	Bay Trail SoC Chipset
System Memory	1 x DDR3L 1333MHz SO-DIMM, Default 4GB, Max. up to 8GB
Ethernet Controller	4 x Intel® I210 GbE LAN
USB	1 x USB 3.0, 3 x USB 2.0 (external) 2 x USB 2.0 by pin-header (internal)

I/O Connectors

Front Side I/O	1 x Power ON/OFF button with LED indicator 1 x Line Out, Line In, Mic In 4 x RJ-45 (Giga LAN) *1 LAN disabled if WLAN Module is added 1 x RS232/422/485 (Switch by jump) Default: RS232 1 x VGA 1 x USB3.0 3 x USB2.0 1 x DC Power 3pin Terminal Block 1 x RS422/485 (Isolation) 1 x 20 pins terminal block DIDO (9in / 9out)

Mechanical and Environment

Dimensions (L x W)	139mm x 65mm x 152mm(L x W x H)
Color	Dark Silver
Construction	Metal housing
Power Input	9~36V DC IN (Isolation)

Mechanical & Environment Specification

Operating Temperature	-20 to 60 deg.C
Operating Humidity	5% to 95% (non condensing)
Certifications	CID2 No. cULus E473882 Class I, Division 2, Groups A, B, C, D; T4 Max. 60oC ATEX No. EPS 15ATEX1981X ATEX II 3 G Ex nA IIC T4 Gc Max. 60oC AWS loT Greengrass Certified
Mounting	Desktop / Wall-Mounting
Power consumption	25W

Product Spec

Storage	Default 64GB mSATA SSD Optional : 64GB to 512GB 2.5″ SSD
OS	Windows Embedded Standard 7 Windows 7 PRO for Embedded system Windows Embedded 8 Standard Windows Embedded 8.1 Industrial Windows 10 IoT Enterprise Ubuntu 18.04 LTS

Výrobce	Winmate
Gigabit LAN	4
Procesor	Celeron
RS-232/422/485 (kombinovaný)	1
RS-422/485 (kombinovaný)	1
USB 2.0	3
USB 3.0	1
VGA	1
Certifikace	ATEX
Použití	Neurčeno
