EACIL20

Fanless Embedded PC, Celeron N3350

Pro zobrazení cen se prosím přihlaste.

Porovnat
Číslo zboží: GW50582005 Produktové číslo: EACIL20Kategorie: Výrobce: Winmate
Poptat produkt

WiFi and 4G LTE. Wireless connectivity and all necessary connectors allow the EACIL20 to send data from manufacturing facilities directly to cloud server. Compact size and rich expansions make EAC mini to be suitable for IoT, smart factory and machine automation applications. The EACIL20 is certified Microsoft Azure for IoT and AWS IoTGreengrass.


Features

  • Intel® Apollo Lake N3350 1.1 GHz
  • Intel® Apollo Lake N4200 1.1 GHz (Option)
  • Fanless cooling system
  • Compact size 100 x 70 x 31 mm (w/o mounting bracket)
  • Expansion module with 30+ combinations
  • Various mounting options: desk, wall, VESA, din-rail, pole
  • Microsoft Azure Certified for IoT
  • AWS IoT Greengrass Certified

  • System Specification

    ProcessorIntel® Apollo Lake N3350 1.1 GHz
    Intel® Apollo Lake N4200 1.1 GHz (Option)
    BIOSInsyde UEFI
    System Memory4GB LPDDR3 1866 MHz
    Graphic InterfaceIntel® HD Graphics
    Expansion SlotmPCIe: 1 x Full-size mPCIe slot
    USB Wafer : 2 x USB Wafer
    Watchdog TimerProgrammable 256 levels, timer interval 1 to 255 sec.
    StorageeMMC: Onboard 32 GB
    mSATA: Optional

    Mechanical and Environment

    Dimensions (L x W)100 (W) x 70 (H) x 31(D) mm(One layer)
    100 (W) x 70 (H) x 61(D) mm(Double layer)
    ConstructionMetal Housing
    Cooling FansNo
    Net Weight (kg) (without touch)0.4 kg (One layer), 0.5 kg (double layer)
    MountingDesk Mounting (Default), Wall Mounting (Default),
    VESA Mounting (Optional), DIN-Rail Mounting (Optional)
    Grounding ProtectionChassis Grounding

    Mechanical & Environment Specification

    Operating Temperature0~55 C
    Operating Humidity10~90% RH
    CertificationsIP30
    Anti-VibrationOperating, IEC 60068-2-64
    Anti ShockOperating, IEC 60068-2-27
    Storage Temperature-15~70 C

    Product Spec

    OSOptional:
    Windows® 10 IoT Enterprise
    Ubuntu 16.04

    Standards and Certification

    CertificationCE / FCC
    Microsoft Azure Certified for IoT
    AWS IoT Greengrass Certified

    Ordering Information

    OptionalOptional Expansion Modules:
    EACWSLT-222 WWAN Expansion Board (Single SIM Slot)
    EACWSLT-231 3-port RS232/422/485 w/ isolation
    EACWSLT-232 16-Channel Digital I/O w/ isolation
    EACWSLT-233 2-port CANBUS w/ isolation
    EACWSLT-234 4-port USB 2.0
    EACWSLT-235 2-port RS232/422/485 w/ isolation
    EACWSLT-236 2-port Giga-LAN
    EACWSLT-237 WWAN Expansion Board (Dual SIM Slot)

    Power Management

    Power Input9V to 36V DC, 2-Pin Terminal Block

    External I/O

    USB2 x USB 3.0
    Ethernet2 x Giga LAN RJ45 Connector
    HDMI1 x HDMI, supports 1920 x 1080@60 Hz

    Others

    LED indicator1 x Power
    Button1 x Power Button
    1 x Reset Button

    Výrobce

    Winmate

    Gigabit LAN

    2

    HDMI

    1

    Procesor

    Celeron

    USB 3.0

    2

    Datasheet

    Stáhnout datasheet:
