EACIL67

Full IP67 Fanless Embedded PC, Celeron N3350

Pro zobrazení cen se prosím přihlaste.

Číslo zboží: GW50581050 Produktové číslo: EACIL67 Kategorie: , Výrobce: Winmate
Poptat produkt

Winmate EAC Mini EACIL67 is an industrial IoT gateway with low power consuming Intel Apollo Lake N3350 processor and full IP67 design. Wireless connectivity and all necessary connectors allow the EACIL67 to send data from manufacturing facilities directly to cloud server. Compact size and full IP67 protection from dust and against the effects of immersion in water make EAC Mini suitable for IoT, smart factory and machine automation applications both indoor and outdoor. The EACIL67 is certified Microsoft Azure for IoT and AWS IoT Greengrass.


Features

  • Intel® Apollo Lake N3350, 1.1 GHz
  • Full IP67
  • USB Type-C Connector with Alt Mode: Display Port A/V output, USB data, Power Delivery
  • Compact size 100 x 115 x 31 mm
  • Fanless cooling system
  • Various mounting options: desk, wall, VESA
  • Suitable for smart factory and outdoor applications

  • System Specification

    ProcessorIntel® Apollo Lake N3350, 1.1 GHz
    BIOSInsyde UEFI
    System Memory4GB LPDDR3 1866 MHz
    Graphic InterfaceIntel® HD Graphics
    Watchdog TimerProgrammable 256 levels, timer interval 1 to 255 sec.
    StorageeMMC: Onboard 64 GB

    Mechanical and Environment

    Dimensions (L x W)100 x 115 x 31 mm
    ConstructionMetal Housing
    Cooling FansFanless
    Net Weight (kg) (without touch)1 kg
    MountingDesk Mounting (Default), Wall Mounting (Default),
    VESA Mounting (Optional)

    Mechanical & Environment Specification

    Operating Temperature-20 C to +60 C
    Operating Humidity10~90% RH (non-condensing)
    CertificationsFull IP67
    Anti-VibrationOperating, IEC 60068-2-64
    Anti ShockOperating, IEC 60068-2-27
    Storage Temperature-30 C to +70C

    Product Spec

    OSOptional:
    Windows® 10 IoT Enterprise
    Ubuntu 18.04

    Standards and Certification

    CertificationCE, FCC, AWS IoT Greengrass Certified, Microsoft Azure Certified for IoT

    Ordering Information

    Optional
  • VESA Mount Kit
  • M12 to Open wire DC with CANBUS Cable
  • Waterproof USB Type-C to Standard USB Type-C Cable
  • Waterproof USB Type-C to Lockable USB Type-C Cable
  • Waterproof RJ45 LAN to Standard RJ45 LAN Cable
  • Waterproof USB Type-A male to Standard USB Type-A female Cable

  • Power Management

    Power Input9V to 36V DC

    Packing List

    Standard Packing List
  • Quick Start Guide
  • Driver CD
  • M12 to Open Wire DC Cable
  • WLAN External Antenna (For EACIL67-101-A464)

  • External I/O

    USB1 x USB 2.0
    1 x USB Type-C [Alt Mode] :
    – Display Port A/V output
    – USB data
    – Power Delivery up to 10W(5V/3A)
    Ethernet2 x Giga LAN

    Výrobce

    Winmate

    Gigabit LAN

    2

    Procesor

    Celeron

    USB 2.0

    1

    USB 3.0

    1

    Certifikace

    Žádná

    Použití

    Neurčeno

    Datasheet

    Stáhnout datasheet:
