R08IB3S-VMU1

8.4″ G-Win VMC, 800×600, Celeron N2930

Pro zobrazení cen se prosím přihlaste.

Porovnat
Číslo zboží: GW31126202 Produktové číslo: R08IB3S-VMU1Kategorie: Výrobce: Winmate
Poptat produkt

8-inch G-WIN Rugged Vehicle Mount Computer-R08IB3S-VMU1-09_0074

Features

  • Ultra Low Power but High Performance Intel® Bay Trail N2920 1.86 GHz Processor Fanless Design
  • High Quality 8.4″ Panel, 800×600 Resolution
  • Full IP65 Dust/water resistant Protection (Except I/O parts)
  • Aluminum Housing with Anti-Corrosion Treatments
  • Anti-Shock and Vibration Standard according to MIL810F/G
  • 4 Wire Resistive Touchscreen / Anti-Reflection Protection Glass (Optional)
  • 802.11 b/g Wireless LAN with Antenna(Optional)
  • Wide Range 9 to 36V DC Input with Isolation
  • Optional 6-60V DC Input, and Optional for Ignition On/Off delay
  • Design to meet EN50155

  • Display Characteristics

    Size8.4″
    Resolution800 x 600
    Pixel Pitch0.213 (H) x 0.213 (V)
    Contrast Ratio600:1 (typ.)
    Brightness600 (typ.)
    Viewing Angle-75~75 (H); -60~70(V)
    Active Display Area170.4 (H) x 127.8 (V)
    Display Color262,144 (6 bits/color)
    Touch(Optional)5 Wire Resistive

    System Specification

    ProcessorIntel® Bay Trail N2930 1.83 GHz
    BIOSAMI 16Mbit Flash
    ChipsetBay Trail SoC Chipset
    Memory1 x DDR3L 1600 MHz SO-DIMM (default 4GB, max. 8GB)
    Wireless (Optional)1x Mini PCI-E base Wireless LAN card with SMA antenna
    Lan ControllerIntel® I210-AT GbE
    StoragemSATA SSD (default 64GB)
    Security SupportTrusted Platform Module (TPM 1.2)

    I/O Connectors

    Back Panel I/O Port2 x RJ-45 (10/100/1000 Mbps)
    1 x HDMI
    1 x DC-in Jack (Phoenix type)
    1 x USB 3.0, 1 x USB 2.0
    1 x RS232/422/485, 1 x RS232
    WLAN antenna SMA in top (Optional)

    In Fornt Control

    Control ButtonPower On/ Off
    Brightness Up
    Brightness Down
    Reset
    Led indicatorPower On/ Off
    HDD Status

    Mechanical and Environment

    Dimensions (W x L x H)277 x 219.5 x 59.7 mm
    Power Input9~36V DC in with Isolation(Phoenix type)
    Optional 6-60V DC in, with Ignition On/Off delay
    Operating Temperature-10C to +55C
    Operation Humidity10% to 95% (non-condensing)
    Shock*Operating: 30g for 18ms, 300m/s
    Vibration*Operating: 1.60/1.96/2.18 g rms for XYZ / 5-500Hz
    Mechanical and Environment* When use SSD or Industrial Compact Flash
    CertificationsCE, FCC Class B,
    MIL-STD-810F/G / IEC60068-2-27 for Vibration /Shock

    Product Option Items

    Mounting Bracket and KitsOne robust bracket with locking handle (Can adjust from -5 to 90)
    Sunlight ReadableTransflective film enhancement (optional)
    OSWindows Embedded Standard 7 (64bit) / Windows Embedded 8.1 Industry Pro (64bit) / Windows 10 IoT Enterprise
    Touch / Anti-reflective Glass3mm Anti-reflective Protection Glass (w/o Touch)
    WLANMini PCI-E base Wireless LAN card with SMA antenna

    Rozměry277 × 219,5 × 59,7 mm
    Výrobce

    Winmate

    Rozlišení

    800 x 600

    Úhlopříčka

    8"

    Datasheet

    Stáhnout datasheet:
