IPD1HB-Front IP65 Industrial Monitor
Technical Description
| Model Name | R05T100-IPD1HB |
| Panel Size | 5.7″ |
| Active Display Area (mm) | 115.2 (H) x 86.4 (V) |
| Resolution | 640×480 |
| Panel Brightness | 900(typ.) |
| Contrast Ratio | 300:1 (typ.) |
| Viewing Angle | -70~70(H) ; -40~60(V) |
| Number of Colors | 262K (6 bits/color) |
| Optional Touch Screen | Resistive Touch, Protective Glass |
| Touch interface | USB / RS232 |
Power Information
| Power Source | 12V DC in, with External AC-DC Adapter(100~240V) |
| Power Consumption | 15 W typical, normal operation |
Display Signals
| Video Input | Standard: 1 x VGA (D-sub 15), 1 x HDMI (Type-A) Optional 1: 1 x VGA (D-sub 15), 1 x S-Video, 1 x Composite |
| OSD User Control | 5 Keys: – , + , Power , Esc , Enter |
Audio
| Audio | Optional Audio line in (3.5mm) + Speaker x 2 |
Environment & Certification
| Operating Temperature (C) | 0~50C |
| Storage Temperature (C) | -10~60 C |
Packing List
| Accessories | Power AC-DC Adapter(100V~240V), VGA cable (1.8m), HDMI cable (2m) |
