R08L100-MLU1

8.4″ Military LCD, 800×600, Res Touch

Pro zobrazení cen se prosím přihlaste.

Číslo zboží: GW61000010 Produktové číslo: R08L100-MLU1 Kategorie: Výrobce: Winmate
Poptat produkt

8-inch G-WIN Military Display


Features

  • High Quality 8.4″ SVGA Panel, 800×600 resolution
  • Full IP65 Dust/water resistant Protection (Except I/O parts)
  • Aluminum Housing with Anti-Corrosion Treatments
  • Anti-Shock and Vibration Standard according to MIL810F & IEC60068-2-27
  • 5 Wire Resistive Touchscreen / Anti-Reflection Protection Glass (Optional)
  • Wide Range 9 to 36V DC Input Acceptable (Optional)

  • Display Specification

    Model NameR08L100-MLU1
    Size8.4″
    Active Display Area170.4(H) x 127.8(V)
    Resolution800 x 600
    Contrast Ratio600:1 (typ.)
    Panel Brightness600(typ.)
    Display Color262,144 (6 bits/ color)
    Viewing Angle-75~75 (H); -70~60 (V)
    Touch5 Wire Resistive
    Mesh Film CoatingOptional

    I/O Connectors

    Back Panel I/O Port1 x VGA (DB-15)
    1x Military Grade Lockable Power Connector
    1x RS232 for Touch Screen (Optional w/ touch)

    In fornt Control

    Control ButtonMenu / Enter Button
    Auto-adjust / Esc Button
    Brightness Up / Increase Button
    Brightness Down / Decrease Button
    Display Power Button
    Led indicatorPower On/ Off
    Display Sleep

    Mechanical and Environment

    Dimensions (W x L x H)277 mm x 219.5 mm x 59.7 mm
    Net Weight (kg) (with touch)2.1
    Power Input12V DC / MIL-grade connector
    Power Consumption15W (typ.)
    Operation Humidity10% to 95% (non-condensing)
    Shock*Operating: 30g for 18ms, 300m/s2
    Vibration*Operating: 1.60/1.96/2.18 g rms for XYZ / 5-500Hz
    CertificationsCE, FCC Class B
    MIL810F/ IEC60068-2-27 for Vibration /Shock
    Storage Temperature-30C ~ 80C
    Operating Temperature-20C ~ 70C

    Product Option Items

    Mounting Bracket and KitsOne robust bracket with locking handle (Can adjust from -5deg. to 90deg.)
    EMI ITO Glass3mm Anti-reflective Protection Glass
    Terminal BlockPluggable 3 pin Terminal Block power input
    Video InputComposite Video, S-Video for optional
    Audio OutAudio Line out for optional
    Wide Power Input Range9V to 36V wide range acceptable for optional

    Hmotnost 2.1 kg
    Rozměry 277 × 219.5 × 59.7 mm
    Výrobce

    Winmate

    Dotyková technologie

    Rezistivní, Volitelná

    Rozlišení

    800 x 600

    Stupeň krytí

    IP65

    Úhlopříčka

    4-9"
