PCI-1710U-DE

100k, 12bit, 16-ch Universal Multifunction PC

Pro zobrazení cen se prosím přihlaste.

Externí sklad: 6 ks

- +
Porovnat
Porovnat
Číslo zboží: GA59101032 Produktové číslo: PCI-1710U-DEKategorie: Výrobce: Advantech
Poptat produkt
• 100 kS/s, 12-bit, 16-ch Universal PCI Multifunction Card
• 16-ch single-ended or 8-ch differential or a combination of analog input
• 12-bit A/D converter, with up to 100 kHz sampling rate
• Programmable gain
• Automatic channel/gain scanning
• Onboard FIFO memory (4,096 samples)
• Two 12-bit analog output channels
• 16-ch digital input and 16-ch digital output
• Onboard programmable counter
• BoardID™ switch

The PCI-1710U Series are multifunction cards for the PCI bus. Their advanced circuit design provides higher quality and more functions, including the five most desired measurement and control functions: 12-bit A/D conversion, D/A conversion, digital input, digital output, and counter/timer.
Hmotnost0,39 kg
Rozměry227 × 159 × 40 mm
Výrobce

Advantech

Počet kanálů

16

Rozhraní

PCI

Typ vstupů

Analogové, Digitální, Čítačové

Typ výstupů

Analogové, Digitální

Datasheet

Stáhnout datasheet:
