EPC-U2117E3W-03Y2W

Intel® Apollo Lake E3900 Series Palm-sized Fanless Embedded PC

Pro zobrazení cen se prosím přihlaste.

Číslo zboží: GAX0006155 Produktové číslo: EPC-U2117E3W-03Y2W Kategorie: Výrobce: Advantech
Poptat produkt
Advantech EPC-U2117 is a plug & play BoX PC design with optimized thermal solution, wide range power input and dedicated I/O for smart kiosk, smart vending machine and digital signage.

Intel® Atom Quad Core/Dual Core Processor
Palm-size form factor: 170 (L) x 117 (W) x 52.6 mm (H)
Supports 2x LAN, 2x COM port (1x RS-232, 1x ccTalk), 1x HDMI, 1x Display Port, 4x USB3.0, CANbus, and DCIN 12~24V
Built-in 1x M.2 expansion slot (PCIe Gen2, USB 2.0 co-lay), 1x Full size Mini PCIe expansion slot (PCIe Gen2, USB 2.0, SATA co-lay)
Supports onboard eMMC, and 1x 2.5 inch storage
Wide Operating Temperature -20 ~ 60 °C (option)
Support SUSI, WISE-DeviceOn and Edge AI Suite.
Hmotnost 1.2 kg
Výrobce

Advantech

Datasheet

Stáhnout datasheet:
