R15IB3S-GSC3(HB)

15″ G-Win PPC, 1024×768, Celeron N2930

Pro zobrazení cen se prosím přihlaste.

Číslo zboží: GW31120745 Produktové číslo: R15IB3S-GSC3(HB) Kategorie: , Výrobce: Winmate
Poptat produkt

R15IB3S-GSC3(HB)-Winmate 15 G-WIN S65 Panel PC


Features

  • 15″ 1024 x 768 Resolution with Projected Capacitive Multi-Touch(P-CAP)screen
  • Intel® Celeron® Bay Trail-M N2930 1.83 GHz
  • Fanless cooling system and ultra low power consumption
  • Edge-to-edge design
  • Special M12 Waterproof connectors
  • Full IP65
  • 1 x LAN, 1 x RS232, 1 x USB

  • LCD PaneláSpecification

    Size15″ TFT
    ActiveáDisplayáArea304.1(H) x 228.1(V)
    PixeláPitch0.297(H) x 0.297(V)
    Resolution1024 x 768
    Contrast Ratio700:1(typ.)
    DisplayáColor16.2M colors (8bits)
    Panel Brightness250 cd/m2(typ.) optional for high brightness 1000 cd/m2 (typ.)
    Viewing Angle-80~80(H);-70~70(V)
    RecommendáResolution1024×768
    Touch ScreenProjected Capacitive Multi-Touch (Default)
    Protection glass (Optional)
    Anti-glare coating (Optional)
    Maximum Colors16.2M colors (8bits)

    SystemáSpecification

    ProcessorIntel® Celeron® Bay Trail-M N2930 1.83GHz
    ChipsetIntel® ATOM SoC Integrated
    Memory2GB DDR3L-1600 SODIMM (Max. 8GB)
    AudioRealtek HD Audio Codec
    StoragemSATA SSD 64GB
    OSWindows 10 IoT Enterprise
    Windows Embedded 8.1 Industry Pro
    Windows Embedded Standard 7
    Security Support Trusted Platform Module (TPM1.2)
    LANDual Intel® I210-AT GbE LAN

    Waterproof IP65 Grade Connectors

    USB Port1 x USB 2.0 (M12 Type)
    Ethernet1 x 10/100/1000 LAN (M12 Type)
    COM Port1 x RS232 (M12 Type) (Optional 422/485)

    Mechanical and Environment

    Operating Temperature-15C to 55C
    Operating Humidity10% to 95% (non-condensing)
    MountingVESA Mount (100 x 100 mm), Panel Mount
    Dimension (W x H x D)363.40 x 277.86 x 44.50 (mm)
    IP ProofFull IP65
    ShockOperating: 40g for 11ms, 300 m/s
    VibrationOperating: 1.48/1.98/2.24 g rms for XYZ/ 5-500Hz

    Power

    Power Input12V DC (M12 type), optional 9-36V DC (M12 Type)
    Power Consumption25W

    Software

    UtilityWatchdog SDK

    Standard and Certification

    CertificationMIL-STD-810F/G for vibration / shock, CE, FCC

    Rozměry 363.4 × 277.86 × 44.5 mm
    Výrobce

    Winmate

    Dotyková technologie

    Kapacitní

    Procesor

    Celeron

    Rozlišení

    1024 x 768

    Stupeň krytí

    IP65

    Typ

    Standardní

    Úhlopříčka

    15"

    Datasheet

    Stáhnout datasheet:
