R15IB3S-65EX

15″ ATEX Stainless PPC, 1024×768, Celeron N2930

Pro zobrazení cen se prosím přihlaste.

Číslo zboží: GW52003163 Produktové číslo: R15IB3S-65EXKategorie: , Výrobce: Winmate
Poptat produkt

R15IB3S-65EX (Full IP65) Flat Stainless for Hazardous Location


Features

  • Class 1, Division 2 & ATEX Zone 2 & IECEx Zone 2
    device certified for hazardous area application
  • Intel® Celeron® Processor N2930
  • 15″ 1024 x 768, 550 nits (Optional 1000 nits) LCD Panel
  • Fanless, streamlined enclosure for highly efficient heat dissipation
  • Projected Capacitive Touch Screen
  • Stainless housing
  • Rated for wide temperature use -20—ÜC to 50—ÜC

  • LCD PaneláSpecification

    Size15″
    ActiveáDisplayáArea304.1 (H) x 228.1 (V)
    PixeláPitch0.297 (H) x 0.297 (V)
    Resolution1024 x 768
    Contrast Ratio700:1 (typ.)
    DisplayáColor16.2M (6 bits + FRC)
    Panel Brightness550 nit, optional 1000 nit
    Viewing Angle-80~80 (H); -70~70 (V)
    Touch ScreenProjected Capacitive Touch Screen

    SystemáSpecification

    ProcessorIntel® Celeron® Processor N2930 2M Cache, 1.83 GHz
    ChipsetIntel® SOC
    Memory4GB DDR3L SO-DIMM 1333 MHz (up to 8GB)
    BIOSAMI BIOS
    WatchdogáTimer256 Levels
    Storage64GB mSATA SSD (optional 128GB, 256GB and 512GB)
    OSWindows 7 Pro for Embedded System 64bit
    Windows Embedded Standard 7 64bit
    Windows Embedded 8.1 Industry PRO 64 bit
    Windows 10 IOT Enterprise 64 bit
    OtherIntel® HD graphics (built-in CPU) video controller

    I/O Connectors

    Serial1 x M12 Type RS232/RS422/RS485(Default RS232)
    DC-Input1 x M21 Type DC power input connector
    USB Port1 x M21 Type USB Type-A Receptacle
    Ethernet1 x M12 Type RJ45 LAN

    Mechanical and Environment

    Operating Temperature-20C to +50C
    Operating Humidity10% to 95% RH, non-condensing
    Cooling SystemFanless
    Dimension (W x H x D)396 x 310 x 49 mm (w/o box cover)
    IP ProofProof IP65 certified, dustproof and waterproof
    ShockMIL-STD-810F/G Method 516.6
    MoutingVESA 100 x 100
    VibrationMIL-STD-810F/G Method 514.6
    DropMIL-STD-810F/G Method 516.6
    EMCCE, FCC

    Power

    Power Input9-36V DC with isolation protection
    Power Adapter12V / 84W AC to DC Adapter
    Power Consumption56W (typ.)

    Peripheral

    LED IndicatorPower, Storage
    ButtonsPower, Reset

    Standard and Certification

    Certification
  • IECEx Zone 2 Certification (applied for)
    nA IIC T4 Gc -20C ATEX Zone 2 Certification (applied for)
    II 3 G Ex nA IIC T4 Gc -20C UL Listing Certification (applied for)
    Class I, Division 2, Groups A, B, C, and D

  • Výrobce

    Winmate

    Procesor

    Celeron

    Rozlišení

    1024 x 768

    Úhlopříčka

    15"

    Dotyková technologie

    Kapacitní

    Stupeň krytí

    IP65

    Typ

    Standardní
