7″ RISC All-in-One Compact Light duty Mobile Data Terminal
TREK-733L is designed as an open platform (RISC) in Android 4.4 with 7″ display all-in-one light duty MDT. 1GHz processor , 1GB memory and LTE provide high speed data with performance required by fleet management company. It offers a build-in battery to backup any emergency condition (UPS). MIL-STD 810G rated can be satisfied by most light duty vehicle vibration condition. Providing wifi, BT and GPS in the same time, the LTE can turn the vehicle into a wireless hub while its built-in GPS can be used for location and route optimization. With optimized antenna, there are three external antenna ports reserved for critical outdoor application.
Vlastnosti:
- NXP (Freescale) Cortex(TM) -A9 i.MX6DL dual-core, 1.0 GHz, SOC, 1GB DRAM,4GB eMMC with Android 4.4.2
- 7″ WSVGA (1024 x 600) LCD with P-CAP touchscreen
- Built-in 4G LTE, WLAN/Bluetooth, and GNSS modules (with optional BeiDou); supports external antennas via SMA to increase sensitivity for 4G LTE and GNSS
- Built-in battery pack (3.6 V, 2400 mAh) offers UPS for emergency notifications and data backups
- Compatible with 12/24 V vehicle power
- MIL-STD-810G certified for shock and vibration tolerance
- 1 x Analog video input to dedicated video processor for real-time display applications
- Multiple isolated DI/O interfaces that support vehicle speed data for distance measurements
- Noise suppression technology for built-in voice recognition applications
