IK70SB7-111-Rugged BOX PC Series – Intel 7th Generation Core i3/i5/i7 Processor BOX PC
Features
System Specification
| Processor | Intel® Core™ i7-7700T, 2.9~3.8 GHz Intel® Core™ i5-7500T, 2.7~3.3 GHz Intel® Core™ i3-7100T, 3.4 GHz |
| BIOS | Insyde BIOS |
| System Chipset | Intel® 8 series Chipset (H170) |
| System Memory | 1 x SODIMM ,Default 4GB Max 16GB DDR4 2400 ›ť›Śz |
| Graphic Chipset | Intel® HD Graphic 630 Supports DirectX 12 and OpenGL 4.4 |
| Ethernet Controller | Intel® I211IT Gigabit-LAN Controller+ I219LM Gigabit-LAN PHY |
| Serial | 1 x RS232, 1 x RS232/422/485 ports |
| USB | 4 x USB 3.0 |
| Expansion Slot | 1 x M.2 slot for Wi-Fi (E key) |
| Storage | 1 x M.2 SSD slot (B Key), Max 512 GB 1 x 2.5″ SATA III SSD/HDD (Optional) |
| Audio | Realtek ALC283 HD codec (Line out, Mic-in) |
I/O Connectors
| Front Side I/O | 1 x Power/HDD LED 1 x Reset / Power on Button |
| Back Side I/O | 2 x RJ-45(10/100/1000 ›ťpbs) 2 x RS-232 Connector (Male) 1 x HDMI 1.4 1 x DP 1.2 4 x USB 3.0 1 x Line out/Mic in |
Mechanical and Environment
| Construction | Aluminum housing |
| Mounting | Desktop/Wall Mount |
Mechanical & Environment Specification
| Operating Temperature | 0~ 50C |
| Operating Humidity | 5% ~ 95% R›Ś (non-condensing) |
Product Spec
| OS | Windows 10 IoT Enterprise Ubuntu 16.04 |
Power Management
| Power Input | 12V DC (Lockable, Power Jack) |
Packing List
| Standard Packing List | 1 x IK70SB7-111 Unit 1 x IK70 Manual & Driver Utility DVD 1 x Wall Mount Kit |
