15-inch G-WIN Rugged Panel PC
Features
Display Characteristics
| Size | 15″ |
| Resolution | 1024 x 768 |
| Pixel Pitch | 0.297 x 0.297 |
| Contrast Ratio | 2000:1 |
| Brightness | 1000 nits(typ.) |
| Viewing Angle | -88~88(H);-88~88(V) |
| Active Display Area | 304.128(H) x 228.096(V) |
| Display Color | 16.2M,8-bits |
| Touch(Optional) | 5 Wire Resistive(Default) |
System Specification
| Processor | Intel® Bay Trail N2930 1.83GHz |
| BIOS | Award 16Mbit Flash |
| Chipset | Bay Trail SoC Chipset |
| Memory | 1 x DDR3L 1066/1333 MHz SO-DIMM (default 4GB, max. 8GB) |
| Wireless (Optional) | 1 x Mini PCI-E base Wireless LAN card with SMA antenna |
| Lan Controller | Intel® I210-AT GbE |
| Storage | mSATA SSD (default 64GB) |
| Security Support | Trusted Platform Module (TPM 1.2) |
I/O Connectors
| Back Panel I/O Port | 1 x USB 3.0, 1 x USB 2.0 1 x HDMI 1 x RS-232 1 x RS-232 (Optional) 1 x RS-232/422/485 1 x 9~36V Terminal Block 1 x CanBus / Digital IO (Optional) 1 x SIM Card Slot (Optional) 2 x LAN |
In Fornt Control
| Control Button | Power On/ Off, Reset, Brightness up& down, Lock& unlock, Auto-dimming&manual dimming, Day& night mode, LED adjustment |
| Led indicator | Power Status, HDD Status |
Mechanical and Environment
| Dimensions (W x L x H) | 398 x 308 x 58 mm |
| Net Weight (kg) (with touch) | 4.6 kg |
| Power Input | 9~36V DC in with Isolation(Phoenix type) Optional 6-60V DC in, with Ignition On/Off delay |
| Operating Temperature | -10C to +55C |
| Operation Humidity | 10% to 95% (non-condensing) |
| Shock* | MIL-STD-810F/G |
| Vibration* | MIL-STD-810F/G |
| Mechanical and Environment | * When use SSD or Industrial Compact Flash |
| Certifications | CE, FCC Class B, MIL-STD-810F/G |
Product Option Items
| Mounting Bracket and Kits | One robust bracket with locking handle (Can adjust from -5deg. to 90deg.) |
| Sunlight Readable | Transflective film enhancement (optional) |
| OS | Windows Embedded Standard 7 (64 bit)/ Windows Embedded 8.1 Industry Pro (64 bit)/ Windows 10 IoT Enterprise |
| Touch / Anti-reflective Glass | 3mm Anti-reflective Protection Glass (w/o Touch) |
| WLAN | Mini PCI-E base Wireless LAN card with SMA antenna |
