R12RK3S-PCM2-POE

12.1" ARM A72+A53 S Series HMI Panel PC

Cena na dotaz

Dostupnost: Na objednávku

Číslo zboží:GWX0001017 Produktové číslo: R12RK3S-PCM2-POE Kategorie:S úhlopříčkou do 13''Výrobce:

Poptat produkt

12.1″ ARM A72+A53 S Series HMI Panel PC

Vlastnosti:

12.1” 1024 x 768 Resolution with Projected Capacitive MultiTouch (PCAP)
Fanless cooling system and ultralow power consumption
Support PoE function
Optional 2MP Front Camera
Optional HF RFID Reader
Stylish design for room booking, access control, and room information applications
Front IP65 Water and Dust Proof

Display

Resolution	1024×768
Size	12.1 inches
Contrast Ratio	1000:1
Panel Brightness	500.0 nits
View Angles	89,89,89,89
Active Area	245.76×184.32 mm
Touch / Glass	Projected Capacitive Multi Touch Screen

System Specification

Processor	ARM A72 (up to 2.0 GHz) + ARM A53 (up to 1.5 GHz)
Memory	2GB LPDDR3L 1600 4GB (Optional)
Storage	Onboard 16GB eMMC Onboard 32GB eMMC (Optional) Mico SD Card SDHC (Optional)
Operating System	Android 7.1
WLAN	Support (Optional)
BT	Support (Optional)
RFID	HF RFID Reader 13.56 MHz (Optional)

Mechanical

Dimension	296 x 227 x 46 mm
Weight	3.0 kg
Mounting	Wall mount VESA mount (Optional)
Enclosure	Metal Housing
Cooling System	Fanless Design
Cut out	282x207mm

Environment

Certification

Certification	CE, FCC

IO Ports

Power Input	1 x 12V DC, 3-Pin Terminal Block
USB Port	1 x USB3.0 (Type-A) 1 x USB2.0 (Type-A) 1 x USB OTG
Serial Port	1 x RS232/422/485 (Default RS232)
SD Card Slot	1 x Micro SD card slot
Video	1 x Micro HDMI (Optional)
Audio	1 x Speaker
Expansion Port	1 x M.2 2242 B-key Slot (for SATA III SSD) 1 x M.2 2230 E-Key Slot (for Wi-Fi module)
LAN	1 x LAN RJ45 Connector with PoE(PD, 802.3 at)

Accessory

Accessory	100~240V AC to DC Adapter Power Cord Terminal Block to 2.5Ø Female Adapter Cable Open Wire Cable with terminal block connector VESA screws
Optional Accessory	VESA Desk Stand (9B0000000412) (Optional)

Power
