10.1″ Windows Rugged Tablet PC with Intel® Celeron® N6211
Features:
- Intel® Elkhart Lake Celeron® N6211 Processor
- 10.1” 1920 x 1200 IPS LED Panel with direct optical bonding
- IP65 water and dust proof with MIL-STD-810H rugged housing
- Low power consumption with fanless design
- Removable battery with hot-swap function for all day productivity
- Sunlight readable with antiglare solution
- USB Type-C port supports power delivery 20V In
- Integrated 4G/5G Wireless WWAN (Optional)
Display
| Resolution | 1920×1200 |
| Size | 10.1 inches |
| Contrast Ratio | 800:1 |
| Brightness | 800 nits |
| View Angles | 85/85/85/85 |
| Touch | Projected Capacitive Multi Touch |
| Viewability | Anti-Glare touch treatment |
| Bonding | Optical Bonding for Sunlight Viewability |
System Specification
| Processor | Intel® Celeron® N6211 @1.20 GHz (up to 3.00 GHz) Intel® Pentium® N6415 (Optional) |
| Memory | 4GB LPDDR4 8GB LPDDR4 (Optional) |
| Storage | 128GB SSD 256GB / 512GB SSD (Optional) Micro SDXC slot supported |
| Operating System | Windows 10 IoT Enterprise LTSC (64 bit) Windows 11 IoT Enterprise LTSC (Optional) |
| Security | TPM 2.0, Kensington Lock |
| Wireless | Wi-Fi, Bluetooth, 4G/5G WWAN (Optional) |
| GNSS | GPS, GLONASS, Galileo, BeiDou |
| RFID | HF RFID (Optional), UHF RFID Reader (Optional) |
| Sensors | Light / G-sensor / Gyro |
| Smart Card Reader | Optional |
Camera
| Front | 2 MP |
| Rear | 8 MP with auto-focus and LED light |
Mechanical
| Dimensions | 271.9 x 197.3 x 19.5 mm |
| Weight | 1.2 kg (standard battery) 1.4 kg (high capacity battery) |
| Cooling | Fanless |
I/O Ports
| USB | 1 x USB 3.0 Type-A 1 x USB 3.0 Type-C (Power Delivery 20V In) |
| SD Slot | 1 x Micro SDXC slot |
| SIM Slot | 1 x SIM card slot |
| Video | 1 x Micro HDMI (Optional) |
| Audio | 3.5mm audio combo jack, dual mics, dual speakers |
| Docking | 1 x 19-pin docking connector |
Environmental
| Operating Temp | -20°C to 60°C |
| Storage Temp | -30°C to 70°C |
| Humidity | 10% to 90% RH (non-condensing) |
| Shock / Vibration | MIL-STD-810G |
| Drop | 4 ft (MIL-STD-810G) |
| IP Rating | IP65 |
Certification
| Certifications | CE, FCC, UL, PTCRB, Verizon |
Battery & Power
| Battery | 7.7V 5900 mAh (Hot-swappable) 7.4V 10280 mAh (Optional) |
| Battery Life | 9 hours (standard), 16 hours (high capacity) |
| Power Adapter | 100–240V AC / 19V DC |
