- 4.3” 480×800 Panel with PCAP Touch
- Android 10 with GMS
- Qualcomm® Snapdragon™ 660 up to 2.2 GHz
- IP65 waterproof and dustproof
- Rear camera: 16M pixels CMOS color camera with auto focus
- Support 1D/2D Barcode Reader
Display
| Size | 4.3 inches |
|---|---|
| Resolution | 480×800 |
| Type | Projected Capacitive Multi Touch |
| Panel Brightness | 650.0 nits |
| Bonding | Optical Bonding for Sunlight Viewability |
System Specification
| Processor | Qualcomm® Snapdragon™ 660 (Octa-Core 2.2 GHz) |
|---|---|
| Memory | 4GB |
| Storage | 64GB |
| Operating System | Android 10 |
| WLAN | Support |
| BT | Support |
| WWAN | 4G (Optional) |
| GNSS | GPS/GLONASS |
| RFID | NFC (Read / Write, Peer to Peer mode) |
| Sensors | Ambient Light Sensor, E-Compass, Gyro, Acceleration Sensors, Proximity Sensor |
Camera
| Rear Camera | 16MP Camera with LED Auxiliary Light (Auto Focus) |
|---|
Mechanical
| Dimension | 185.1x 77 x 33.7 mm |
|---|---|
| Weight | 323g |
IO Ports
| USB Port | 1 x USB 3.1 Type C OTG (support charging) |
|---|---|
| Audio | 1 x Built-in Mic 1 x Speaker 1 x Receiver |
| SD Card Slot | 1 x Micro SD Card Slot |
| SIM Card Slot | 1 x Nano SIM Card Slot |
| Indicator | 1 x LED Indicator |
Environment
| Operating Humidity | 5% to 90% RH, Non-Condensing |
|---|---|
| Operating Temperature | -20°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Shock | MIL-STD-810G Method 516.6 Procedure I |
| Vibration | MIL-STD-810G Method 514.6 Procedure I |
| Drop | 1.8m MIL-STD 810G with boot and 1.6m MIL-STD 810G |
| IP rating | IP65 |
Certification
| Certification | CE. FCC, CB, UKCA, IC, NCC, NTC Class B, RoHS, REACH, WEEE, CP65 |
|---|
Control
| Button | Physical keypad type (23 keys) with white color backlight, Scan key x 2, Volume key x 2, Power key |
|---|
Power
| Battery | 3.85V 4000mAh (Default) Hotswappable Function (Optional) |
|---|---|
| Power Rating | 5V/ 9V |
Accessory
| Accessory | Adapter Data Cable (Type C) LCM Protector Hand Strap |
|---|---|
| Optional Accessory | Spare Battery (Optional) Protective Boot (Optional) Cradle (1 Terminal + 1 External Battery) (Optional) |
Barcode Scanner
| Barcode Scanner | 1D/2D 30° Barcode Reader |
|---|
