• Robust 15-ch Digital I/O Module with Modbus
• 7 input channels and 8 output channels
• Broader Operating Temperature Range
• Higher Noise Immunity: 1 kV surge protection on power inputs, 3 kV EFT, and 8 kV ESD protection
• Broader Power Input Range: +10 ~ +48 VDC
• LED display allows to monitor the status address settings
• Digital Filter Function
• DI channels can be used as 1 kVGz counters
• Over current/ short circuit protection
• DO channels support pulse output function
The ADAM-4100 series modules are compact, versatile sensor-to-computer interface units designed for reliable operation in harsh environments. Their built-in microprocessors, encased in rugged industrial-grade ABS plastic, independently provide intelligent signal conditioning, analog I/O, digital I/O, LED data display, and an address mode with a user-friendly design for convenient address reading.
