Designed to deliver medical images of optimal quality, the PAX-324 monitor supports a Full HD resolution of 1920×1200 @ 60 Hz. Equipped with DICOM Part 14 GSDF compliance 14-bit LUT processing grayscale, hardware calibration support, and automatic charge input detection, the PAX-324 surgical monitor ensures precise representation of grayscale images and its slim true-flat design also offers physical onscreen display keys, a splash screen and an optional touchscreen with projective capacitive control, and can be upgraded into an IP-based monitor.
Operational 0~40°C / Storage -20~60°C
Optional upgrade to an IP-based monitor with AVAS
Video enhancement features include: •14-bit LUT processing •DICOM Part 14 GSDF compliant •DICOM, clear, blue modes supported
Multi-standard video support (NTSC, PAL, SECAM)
SDI support up to 1920 x 1080 @ 60Hz
HDMI 2.0, DP 1.2, DVI, RGB support up to 1920 x 1200 @ 60 Hz
FHD resolution (1920 x 1200)
High brightness display with a high contrast ratio
24″ true-flat monitor with AR filter
